DP 300 (Multi-stage Dry Vacuum Pump )

A compact, self-sustained pumping system

Home / Products / Dry vacuum pumps / Multistage Dry Claw Vacuum Pumps / DP300

DP300

Innovative multi-stage vacuum excellence

The DP300 is a multi-stage dry vacuum pump composed with a pair of lobes and a pair of claw rotors rotating opposite in a synchronous way within the pump casing to form suction and discharge operation. Oil-free, non-contacting, four stage roots and hook and claw arrangement makes it more suitable for pumping air and other gases. It provides consistent vacuum with high efficiencies, lowest cost of ownership with adequate safety and performance standards. The new pump is of 300m3 /h capacity with an ultimate vacuum of less than 1mbar.

Variants of the DP300.

DP300 :

The DP300 is the standard multi-stage dry vacuum pump that can be further upgraded by adding a roots booster from our RD series.

DP300S :

The DP300S is a compact multi-stage dry vacuum pumping system that is fully automated. As a self-sustained vacuum pumping system designed with all essential safety features, it is an industry-ready, reliable plug-and-play standalone unit.

DP300H :

The DP300H is a horizontal configuration of its predecessor DP300. One of our latest introductions to the market preferred for process applications. Contact-free operation and higher compression ratio helps to pump faster and maintain a consistent vacuum.

Features of DP300

Relief valve

Water cooled

Vertical mount

Compact design

Angular contact bearing

Four stage compression

Cartridge-type inlet side bearing

Features of DP300S

Inlet purge

Simple yet intelligent direct cooling

Solvent purge

Shaft seal purge

Industries.

The DP300 multistage dry vacuum pumps deliver well on performance making them a good choice for industries like chemical, food, medical, electrical and power.

Chemical and Process Industries

Electrical & Power

Food

Medical

Typical Applications of DP300 series

Freeze drying

Vacuum pumps for freeze drying removes moisture from the frozen product by sublimation, ensuring efficient and complete drying.

Drying

Vacuum pumps facilitate controlled evaporation of solvents or moisture from samples like chemicals, pharmaceuticals or foodstuffs.

Distillation

Vacuum technology enables distillation by safely and effectively separate liquids with very high boiling point or are explosive by lowering the pressure of surroundings. Ideal for pharma and chemical industry use.
